  • Description

    FR-200 Frame Saw
    Key Advantages
    Feed Rolls & Pressure Rolls
    Bottom Rolls – 7 pieces in Front Section & 5 pieces in Rear Section
    Top Front section is equipped with 7 pressure rollers & 3 air cylinders controlled by sensor
    Top Rear section is equipped with 5 pressure rollers & 1 air cylinder controlled by sensor

  • Specs

    Motor 20 HP + ½ HP + 5 kW (Servo ) + 2 HP Blower
    Max. Working Thickness 200 mm
    Min. Working Thickness 60 mm
    Max. Working Width 150 mm
    Min. Working Length 300 mm
    Feed Speed 0.1~2.0 m/min
    Main Shaft Speed 480 RPM, stroke distance 210 mm
    Saw blade Size 500 x 40 x 0.8 mm, Kerf: 1.2 mm, Pitch: 15, Stellite
    Max Saw blades 24 Pieces
    Finished Tolerance Value ± 0.1 mm
    Min Precision Thickness 2.0 mm
    Dust Pipe 5″x 4 Pieces
    Machine Dimensions L3800 x W1000 x H1900 mm

Videos of Frame Saw

CANTEK FR-200 Frame Saw
