C5 | Safety Speed | Panel Saws

  • Description

    The C5 model packs all of the features of the full-size saws into a portable 5′ frame while featuring a 64″ maximum crosscut . This panel saw can travel to work sites and fit into shops with limited floor space. The only difference between this machine and the C4 Panel saw are the maximum crosscut lengths. Standard Equipment:


    *Zinc plated 1 ¾” steel guide tubes.

    4 Nylatron roller bearing systems.

    *Adjustable vertical and horizontal rulers.

    *Quick change from vertical to horizontal cutting.

    *Thin material pressure guard.

    *Injection-molded plastic material rollers.

    *Spring loaded counter balance system.

    *Integrated dust collection bonnet.

    *TUV certified to UL/CSA standards

  • Specs

    Weight|219 lbs

    Dimensions|60 × 11 × 83 in

    Max. Crosscut|64″/1625mm

    Max. Rip Cut|96″/2450mm

    Cut Depth|1 ¾”/45mm

    Cut Accuracy|1/32″/.8mm

    Frame Length|60″/ 525mm

    Daily Usage|1-3 Hours

    Rollers|8

    Saw Blade Diameter|8″/210mm

    Motor amps and volts|15 amp, 120 Volt, 7.5 amp, 220 Volt

    Motor Manufacturer|Milwaukee Tool
